The WH-1050S is an automatic die cutting and creasing machine designed for the packaging and printing industry. It provides precise die cutting, creasing, and embossing for paper, cardboard, and corrugated board materials.
Key Features:
- High-precision die cutting and creasing
- Automatic feeding and delivery system
- Pneumatic clutch for smooth operation
- Force-adjustable die cutting system
- Centralized lubrication system
- Safety protection devices (infrared sensors)
Technical Parameters:
- Max sheet size: 1050 x 750mm
- Min sheet size: 350 x 300mm
- Die cutting speed: 5000-8000 sheets/hour
- Max die cutting pressure: 300 tons
- Power: 380V/50Hz, 12kW
- Machine weight: ~8000kg
